HCPL2611 RoHS (A2611)
(0) Yorum - 0 Puan
151,16 TL
RoHS:RoHS Compliant Details
Package/Case:PDIP-8
Data Rate:10 Mbps
Number of Channels:1 Channel
Output Type:Open Collector
Isolation Voltage:5000 Vrms
Vf - Forward Voltage:1.4 V
If - Forward Current:10 mA
Vr - Reverse Voltage:5 V
Pd - Power Dissipation:100 mW
Maximum Operating Temperature:+ 85 C
Minimum Operating Temperature:- 40 C
Series:HCPL2611
Packaging:Bulk
Brand:ON Semiconductor / Fairchild
Fall Time:12 ns
Height:3.94 mm
Length:9.91 mm
Maximum Collector Current:50 mA
Output Current:50 mA
Rise Time:50 ns
Factory Pack Quantity:1000
Width:6.86 mm
Part # Aliases:HCPL2611_NL
Unit Weight:819 mg
