G5LE-1-12V DC
39,40 TL
Kategori
Marka
Dorukan Stok No
DRK-4544-45
Fiyat
0,90 EUR + KDV
Havale
38,22 TL
(%3,00 havale indirimi)
A Cubic, Single-pole 10-A Power Relay
Subminiature "sugar cube” relay with universal terminal footprint.
Conforms to VDE0435 (VDE approval: B250 Insulation grade), UL508, CSA22.2.
Tracking resistance: CTI>250 (-VD type).
UL class-F coil insulation model available (UL class-B coil insulation for standard model).
High switching power: 10 A.
Two types of seal available; flux protection and fully sealed.
Withstands impulse of up to 4,500 V.
400-mW and 360-mW coil power consumption types available.
Pre-soldered terminals.
