FDS8949
132,77 TL
Kategori
Marka
Dorukan Stok No
DRK-2268-FB
Fiyat
3,15 USD + KDV
| Product Attribute | Attribute Value | Search Similar |
|---|---|---|
| Manufacturer: | ON Semiconductor | |
| MOSFET | ||
| RoHS: | Details | |
| Technology: | Si | |
| Mounting Style: | SMD/SMT | |
| Package/Case: | SO-8 | |
| Transistor Polarity: | N-Channel | |
| Number of Channels: | 2 Channel | |
| Vds - Drain-Source Breakdown Voltage: | 40 V | |
| Id - Continuous Drain Current: | 6 A | |
| Rds On - Drain-Source Resistance: | 21 mOhms | |
| Vgs - Gate-Source Voltage: | - 20 V, + 20 V | |
| Vgs th - Gate-Source Threshold Voltage: | 1 V | |
| Qg - Gate Charge: | 11 nC | |
| Minimum Operating Temperature: | - 55 C | |
| Maximum Operating Temperature: | + 150 C | |
| Pd - Power Dissipation: | 2 W | |
| Channel Mode: | Enhancement | |
| Tradename: | PowerTrench | |
| Packaging: | Reel | |
| Packaging: | Cut Tape | |
| Packaging: | MouseReel | |
| Brand: | ON Semiconductor / Fairchild | |
| Configuration: | Dual | |
| Fall Time: | 3 ns | |
| Forward Transconductance - Min: | 22 S | |
| Height: | 1.75 mm | |
| Length: | 4.9 mm | |
| Product Type: | MOSFET | |
| Rise Time: | 5 ns | |
| Series: | FDS8949 | |
| Factory Pack Quantity: | 2500 | |
| Subcategory: | MOSFETs | |
| Transistor Type: | 2 N-Channel | |
| Type: | MOSFET | |
| Typical Turn-Off Delay Time: | 23 ns | |
| Typical Turn-On Delay Time: | 9 ns | |
| Width: | 3.9 mm |
