ATN206(TN2-4.5V)
153,25 TL
Kategori
Marka
Dorukan Stok No
DRK-ARKARAFROLE,.
Fiyat
3,00 USD + KDV
| Product Number | TN2-4.5V |
|---|---|
| Part Number | ATN206 |
| Product details | Single side stable type, Standard PC board terminal, 4.5V DC |
| Protective construction | Sealed Type |
| Terminal shape | Standard PC board terminal |
| Contact arrangement | 2 Form C |
| Contact material | Ag+Au clad |
| Operating function | Single side stable type |
| Rated operating power | 140mW |
| Rated coil voltage | 4.5V DC |
| Pick-up voltage (at20℃) | 75%V or less of nominal voltage (Initial) |
| Drop-out voltage (at20℃) | 10%V or more of nominal voltage (Initial) |
| Contact rating (resistive load) | 1 A 30 V DC, 0.5 A 125 V AC |
| Max.switching current | 1 A |
| Min. switching capacity | 10μA 10mV DC |
| Breakdown voltage (Initial) : Between open contacts | 750 Vrms for 1min. (Detection current: 10mA.) |
| Breakdown voltage (Initial) : Between contact and coil | 1,000 Vrms for 1min. (Detection current: 10mA.) |
| Breakdown voltage (Initial) : Between contact sets | 1,000 Vrms for 1min. (Detection current: 10mA.) |
| Surge withstand voltage (initial): Between open contacts | 1,500 V (10 x 160μs) (FCC Part 68) |
| Expected life : Mechanical | Min. 108 (at 180 cpm) |
| Expected life : Electrical | Min. 2 x 105 (1 A 30 V DC resistive), Min. 105 (0.5 A 125 V AC resistive) (at 20 cpm) |
| Conditions | Ambient temperature: –40 to +70℃ –40 to +158°F Humidity: 5 to 85% R.H. (Not freezing and condensing at low temperature) |
| Unit weight | Approx. 1.5 g .053 oz |
| Packing style | Tube packing |
