6x6mm Tact Switch Dik
4,32 TL
Kategori
Dorukan Stok No
KEHRSTXZ1
Fiyat
0,10 USD + KDV
Havale
4,19 TL
(%3,00 havale indirimi)
Rated Voltage(DC)
15V
Rated Current
Max : 20mA
Contact Resistance
Max : 0.05Ohm
Poles
1
Positions
2
Travel
0.25 ± 0.2mm
Operation Force
160±50gf
Direction of Operation
Horizontal Type
Nonspecified Dimensions Tolerance
±0.3
Packing Type
Taping
|
Rated Voltage(DC) |
| 15V |
|
Rated Current |
| Max : 20mA |
|
Contact Resistance |
| Max : 0.05Ohm |
|
Poles |
| 1 |
|
Positions |
| 2 |
|
Travel |
| 0.25 ± 0.2mm |
|
Operation Force |
| 160±50gf |
|
Direction of Operation |
| Horizontal Type |
|
Nonspecified Dimensions Tolerance |
| ±0.3 |
|
Packing Type |
| Taping |
