47uH 1800mA Kondansatör Tipi Bobin (CH8010470K RoHS)
8,82 TL
Marka
Dorukan Stok No
DKX74X627
Fiyat
0,20 EUR + KDV
Havale
8,56 TL
(%3,00 havale indirimi)
| Features |
| • High-frequency ferrite core • Comparatively large rated current • Radial leads |
 |
| Technical Specifications |
|
|
| Temperature Range: |
-20...+80°C |
| Inductance (DL): |
±10% |
|
|
| Part Nr. |
L |
Q |
fQ |
f |
RDC |
IN |
| [µH] |
[MHz] |
[MHz] |
[W] |
[mA] |
||
| CH8010470K | 47 | 30 |
2,52 |
6,3 | 0,098 | 1800 |
|
L = Inductance, Q = Quality Class, Min., fQ = Testing Frequency of L and Q, f = Resonance Frequency, Min., RDC = DC Resistance, Max., IN = Rated DC Current
|
||||||
 |
||||||
